Quectel
Quectel is the leading global supplier of cellular and GNSS modules, with a broad product portfolio covering the most recent wireless technologies of 5G, LTE/LTE-A, NB-IoT/LTE-M, UMTS/HSPA(+), GSM/GPRS and GNSS. Tekdis offers a range of LTE and 5G modules for integration into our embedded and vehicle PC solutions. Focus is on Telstra approved modules in mPCIe and M.2 formfactors.
-
RM520N-GL 5G Sub-6 GHz M.2 Module5G Sub-6 GHz M.2 Module optimized specially for IoT/eMBB applications
Key Features:
- 5G/4G/3G multi-mode module with M.2 form factor, optimized for IoT and eMBB applications
- Worldwide 5G and LTE-A coverage
- Both NSA and SA modes supported
- Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
- Feature refinements: DFOTA and VoLTE (optional)
-
EM120K-GL LTE-A Cat 12 M.2 ModuleLTE-A Cat 12 M.2 Module 600Mbps/150Mbps
Key Features:
- LTE-A Cat 12 module with M.2 form factor
- Support DL 3 Carrier Aggregation and 256QAM
- Worldwide LTE-A and UMTS/ HSPA+ coverage
- Built-in eSIM (optional), DSSA
- Low power mode
- Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
- MIMO technology meets demands for data rate and link reliability in modem wireless communication systems
-
RM502Q-GL - IoT/eMBB-Optimized 5G Sub-6 GHz M.2 ModuleThe RM502Q-GL is a 5G sub-6GHz M.2 module measuring 52.0mm × 30.0mm × 2.3mm which supports both standalone (SA) and non-standalone (NSA) modes.
-
EG25-G - LTE Cat 4 mPCIe with Sim HolderQuectel EG25-G Mini PCIe is an LTE category 4 module adopting standard PCI Express® Mini Card form factor (Mini PCIe). It is optimized specially for M2M and IoT applications, and delivers maximum data rates up to 150Mbps downlink and 50Mbps uplink.
-
EM06 - LTE-A Cat 6 M.2 ModuleLTE-A Cat 6 module with M.2 form factor, optimized for M2M, Support LTE-A carrier aggregation ,Worldwide LTE-A and UMTS/HSPA(+) coverage, Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment, Feature refinements: supports DFOTA and DTMF, MIMO technology meets demands for data rate and link reliability in modem wireless communication systems.
-
EC25 - LTE Cat 4 mPCIe ModuleLTE category 4 module optimized for broadband IoT applications, Worldwide LTE, UMTS/HSPA(+) and GSM/GPRS/EDGE coverage, Standard PCI Express® Mini Card form factor (Mini PCIe) ideal for manufacturers to easily integrate wireless connectivity into their devices, MIMO technology meets demands for data rate and link reliability in modem wireless communication systems.
-
EC21 - LTE Cat 1 mPCIe ModuleCost-effective, lower-power LTE connectivity optimized for broadband IoT applications Worldwide LTE, UMTS/HSPA+ and GSM/GPRS/EDGE coverage Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment.
