MSata SSD MSA452T-I

Dimensions

50.8 mm x 29.85 mm x 4.85 mm (2" x 1.18" x 0.19")

Weight

8 g (0.28 oz)

mSATA Type

MO-300

Pin

52 pin

Form Factor

• mSATA

Interface

Bus Interface

• SATA III 6Gb/s

Storage

Flash Type

• 3D TLC NAND flash

Capacity

• 64 GB/

• 128 GB/

• 256 GB/

• 512 GB/

• 1 TB

Operating Environment

Operating Voltage

• 3.3V±5%

Operating Temperature

• Standard

0°C (32°F) ~ 70°C (158°F)



• Wide Temp.

-40°C (-40°F) ~ 85°C (185°F)

Storage Temperature

-40°C (-40°F) ~ 85°C (185°F)

Humidity

5% ~ 95%

Shock

• 1500 G, 0.5 ms, 3 axis

Vibration (Non-operating)

2.17 G (peak-to-peak), 10 Hz ~ 700 Hz (frequency)

Power

Power Consumption (Operation)

2.4 watt(s)

Power Consumption (Sleep)

0.4 watt(s)

Performance

Sequential Read/Write (CrystalDiskMark, max.)

Read: 560 MB/s Write: 520 MB/s

4K Random Read/Write (IOmeter, max.)

Read: 95,000 IOPS Write: 85,000 IOPS

Mean Time Between Failures (MTBF)

3,000,000 hour(s)

Terabytes Written (Max.)

1,760 TB

Drive Writes Per Day (DWPD)

1.61 (3 yrs)

Note

• Speed may vary due to host hardware, software, usage, and storage capacity.

• The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
