IGS-C1080 8-port Unmanaged Gigabit Industrial Switch
Industrial 8-port unmanaged Gigabit Ethernet switch
Key Features:
- Supports 8 x 10/100/1000Base-T(X), RJ45 connector
- Compact size for easy installation
- QoS supported to process critical data in heavy traffic
- IP40 protection class
- -40 to 75°C wide operating temperature range
- DIN-Rail mounting enabled
Enquire Now
Enquire about this product:
The IGS-C1080 line of gigabit Ethernet switches have 8 x10/100/1000Base-T(X) RJ45 ports and are unmanaged. A broad operating temperature range of -40°C to 75°C can also accommodate the majority of operating environments. As a result, the switch is among the most trustworthy options for Ethernet applications.
Key Features:
- Supports 8 x 10/100/1000Base-T(X), RJ45 connector
- Compact size for easy installation
- QoS supported to process critical data in heavy traffic
- IP40 protection class
- -40 to 75°C wide operating temperature range
- DIN-Rail mounting enabled
| ORing Switch Model | IGS-C1080 |
| Physical Ports | |
|
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX |
8 |
| Technology | |
| Ethernet Standards | IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3ab for 1000Base-T IEEE 802.3x for Flow control |
| MAC Table | 4k |
| Packet Buffer Size | 1.5Mbits |
| Processing | Store-and-Forward |
| DIP Switch | Quality of Service (QoS), Broadcast Storm Protection (BSP) |
| Power | |
| Single Input Power | 12~48VDC on 2-pin terminal block. |
| Overload Current Protection | Present |
| Reverse Polarity Protection | Present |
| Physical Characteristics | |
| Enclosure | IP-40 |
| Dimensions (W x D x H) | 43.5 × 103 × 64mm |
| Environmental | |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Operating Temperature | -40 to 75°C (-40 to 167°F) |
| Operating Humidity | 5% to 95% Non-condensing |
| Regulatory Approvals | |
| EMC | CE EMC (EN 55032, EN 55035), FCC Part 15 B |
| EMI | CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A |
| EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000- 4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8(PFMF) |
| Safety | EN62368-1 |
