IGS-1082GP 10 port Unmanaged GbE Switch
IGS-1082GP 10 port Unmanaged GbE Switch
Industrial 10-port unmanaged Gigabit Ethernet switch with 8x10/100/1000Base-T(X) and 2x100/1000Base-X, SFP socket
Key Features:
- 8 ports IEEE 802.3at compliant PoE
- Total power budget is 180Watts
- Up to 9.6K Bytes Jumbo Frame
- Support up to 4Mbit Packet buffer
- Support store and forward transmission
- Support flow control
- Provided relay output for power failed warning system
- Provide DIP switch for setting SFP speed
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
Description
- Support 9.6K Bytes Jumbo Frame
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- Support up to 9.6K Bytes Jumbo Frame
- Support up to 4Mbit Packet buffer
- Support wide range power input 12~48VDC
- Provide DIP-switch to setting SFP speed
- Provided relay output for power failed warning system
- Rigid IP-30 housing design
- DIN-Rail and wall mounting enabled
More Information
|
Brand |
Oring |
|
Specifications |
| Physical Ports |
|
| 10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX |
8 |
| 100/1000Base-X with SFP port |
2 |
| Technology |
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE 802.3x for Flow control |
| MAC Table |
8k |
| Processing |
Store-and-Forward |
| Switch Properties |
Switching latency: 7 us
Switching bandwidth: 20Gbps |
| Jumbo frame |
Up to 9.6K Bytes |
| Packet buffer |
4Mbit |
| LED Indicators |
|
| Power Indicator (PWR) |
Green : Power LED x 3 |
| Fault Indicator |
Amber : Indicate power failed even warning |
| 10/100/1000Base-T(X) RJ45 Port Indicato |
Green for port Link/Act.
Dual color LED for speed indicator ~ Green for 1000Mbps / Amber for 100Mbps / off-light for 10Mbps
|
| 100/1000Base-X SFP Port Indicator |
Green for port Link/Act. |
| DIP Switch |
|
| DIP-Switch 1 |
Power-1 failed warning : (ON) enable, (OFF) disable |
| DIP-Switch 2 |
Power-2 failed warning : (ON) enable, (OFF) disable |
| DIP-Switch 3 |
DIP switch 3 and 4 (ON) : SFP speed setting to 100Mbps |
| DIP-Switch 4 |
DIP switch 3 and 4 (OFF) : SFP speed setting to 1000Mbps(default) |
| Fault Contact |
|
| Relay |
Relay output to carry capacity of 1A at 24VDC |
| Power |
|
| Redundant Input Power |
Dual DC inputs. 12~48 VDC on 6-pin terminal block |
| Power Consumption (Typ.) |
10 Watts |
| Overload Current Protection |
Present |
| Reverse Polarity Protection |
Present |
| Physical Characteristics |
|
| Enclosure |
IP-30 |
| Dimensions (W x D x H) |
54.3(W) x 108.3(D) x 145.1(H) mm (2.13x4.26x5.71 inches.) |
| Weight (g) |
837g |
| Environmental |
|
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Operating Temperature |
-40 to 75°C (-40 to 167°F) |
| Operating Humidity |
5% to 95% Non-condensing |
| Regulatory Approvals |
|
| EMC |
EN55032, EN55024(CE EMC), FCC Part 15B, EN61000-3-2, EN61000-3-3 |
| EMI |
CISPR 32, EN55032, FCC Part 15B class A |
| EMS |
IEC 61000-4-2 (ESD), IEC 61000-4-3 (RS), IEC 61000-4-4 (EFT), IEC 61000-4-5 (Surge), IEC 61000-4-6 (CS), IEC 61000-4-8 (PFMF), IEC 61000-4-11 (DIP) |
| Shock |
IEC60068-2-27 |
| Free Fall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6 |
| Safety |
EN60950-1 compliant |
| MTBF |
TBD |
| Warranty |
5 years |
|
