IGS-1041GPA 5-Port Unmanaged Ethernet Switch
View larger image
IGS-1041GPA 5-Port Unmanaged Ethernet Switch
Industrial Slim Type 5-Port Unmanaged Gigabit Ethernet Switch
Description
• Each unit supports 5 x 10/100/1000Base-T(X) ports or 4 x 10/100/1000Base-T(X) and 1 x 1000Base-X SFP ports
More Information
Specifications
Physical Ports
1000Base-X SFP Ports
1
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX
4
Technology
Ethernet Standards
IEEE 802.3 for 10Base-T
MAC Table
1024 MAC addresses
Processing
Store-and-Forward
Jumbo Frame
9K
LED Indicators
Power Indicator
Green : Power LED x 2
Fault Indicator
Amber : Indicates PWR1 or PWR2 failure occurred
1000Base-X SFP Port Indicator
Green for port Link/Act
10/100/1000Base-T(X) RJ45 Port Indicator
Green for port Link / Act Amber for 100Mbps indicator
Fault Contact
Relay
Relay output to carry capacity of 1A at 24VDC
Power
Redundant Input Power
Dual DC inputs. 12~48 VDC on 6-pin terminal block
Power Consumption (Typ.)
5.5 Watts
Overload Current Protection
Present
Reverse Polarity Protection
Present
Physical Characteristics
Enclosure
IP-30
Dimensions (W x D x H)
26.1(W) x 94.9(D) x 144.3(H) mm ( 1.03x3.74x5.68 inch.)
Weight (g)
403g
Environmental
Storage Temperature
-40 to 85°C (-40 to 185°F)
Operating Temperature
-40 to 70°C (-40 to 158°F)
Operating Humidity
5% to 95% Non-condensing
Regulatory Approvals
EMI
FCC Part 15, CISPR (EN55022) class A
EMS
IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11
Shock
IEC60068-2-27
Free Fall
IEC60068-2-32
Vibration
IEC60068-2-6
Safety
EN60950-1
Warranty
5 years
