Specifications |
|
Picture/Display
|
|
Diagonal screen size
|
85.6 inch / 217.4 cm
|
|
Panel resolution
|
3840x2160
|
|
Optimum resolution
|
3840x2160 @ 60 Hz
|
|
Brightness
|
400 cd/m²
|
|
Dynamic contrast ratio
|
500,000:1
|
|
Response time (typical)
|
8 ms
|
|
Aspect ratio
|
16:9
|
|
Viewing angle (H / V)
|
178 / 178 degree
|
|
Pixel pitch
|
0.4296 x 0.4296 mm
|
|
Display colors
|
1.07 Billion
|
|
Panel technology
|
IPS
|
|
Contrast ratio (typical)
|
1200:1
|
|
Clinical image
|
D-Image preset (dicom part 14 compatible)
|
|
Haze
|
25%
|
|
Supported Display Resolution (Computer Format)
|
|
Resolution
|
Refresh Rate
|
|
640 x 480
|
60, 67, 72, 75Hz
|
|
720 x 400
|
70Hz
|
|
800 x 600
|
56, 60, 72, 75Hz
|
|
832 x 624
|
75Hz
|
|
1024 x 768
|
60, 70, 75Hz
|
|
1152 x 864
|
75Hz
|
|
1152 x 870
|
75Hz
|
|
1280 x 720
|
60Hz
|
|
1280 x 800
|
60Hz
|
|
1280 x 1024
|
60Hz
|
|
1440 x 900
|
60Hz
|
|
1600 x 1200
|
60Hz
|
|
1680 x 1050
|
60Hz
|
|
1920 x 1080
|
60Hz
|
|
Supported Display Resolution (Video Format)
|
|
Resolution
|
Refresh Rate
|
|
480i
|
60Hz
|
|
480p
|
60Hz
|
|
576p
|
50Hz
|
|
576i
|
50Hz
|
|
720p
|
60Hz
|
|
1080i
|
50, 60Hz
|
|
1080p
|
50, 60Hz
|
|
3840 x 2160
|
30Hz
|
| 3840 x 2160 |
60Hz |
|
Connectivity
|
|
Video input
|
DVI-I (x 1), HDMI 2.0 (x2), USB 2.0 (x2)
|
|
Audio input
|
3.5 mm jack
|
|
Audio output
|
3.5mm jack
|
|
External control
|
IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack
|
|
Other connections
|
OPS
|
|
Convenience
|
|
Placement
|
Landscape (18/7), Portrait (18/7)
|
|
Tiled Matrix
|
Up to 10 x 15
|
|
Signal loop through
|
RS232, IR Loopthrough
|
|
Ease of installation
|
Smart Insert
|
|
Energy saving functions
|
Smart Power
|
|
Network controllable
|
RS232, RJ45
|
|
Keyboard control
|
Hidden, Lockable
|
|
Remote control signal
|
Lockable
|
|
Start-up
|
Switch on delay, Switch on status, Boot on source
|
|
Start-up window
|
enable / disable Philips logo
|
|
Operating Conditions
|
|
Temperature range (operation)
|
0 ~ 40 °C
|
|
Temperature range (storage)
|
-20 ~ 60 °C
|
|
Altitude
|
0 ~ 3000 m
|
|
MTBF
|
50,000 hour(s)
|
|
Humidity range (operation)[RH]
|
20 ~ 80% RH (No condensation)
|
|
Humidity range (storage) [RH]
|
5 ~ 95% RH (No condensation)
|
|
Power
|
|
Consumption (Typical)
|
360 W
|
|
Consumption (Max)
|
500 W
|
|
Standby power consumption
|
<0.5W
|
|
Mains power
|
100 - 240V~, 50/60Hz
|
|
Power Saving Features
|
Smart Power |
|
Energy Label Class
|
G |
|
Sound
|
|
Built-in speakers
|
2 x 10W RMS
|
|
Accessories
|
|
Included Accessories
|
IR sensor cable (1.8 m) (x1), Philips logo (x1), AC power cord, AC Switch Cover, Quick start guide (x1), Remote control & AAA batteries, RS232 daisy chain cable (x1), USB Cover and screw x1, Wire Clamper (x3)
|
|
Miscellaneous
|
|
On-Screen Display Languages
|
Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese
|
|
Regulatory approvals
|
CE, FCC, Class A, CB, BSMI, EPA, VCCI, CU, ETL, EMF, PSB
|
|
Warranty
|
3 year warranty
|
|
Multimedia Applications
|
|
USB Playback Video
|
H.264, JPEG, MPEG, WMV3
|
|
USB Playback Picture
|
BMP, JPEG, PNG
|
|
USB Playback Audio
|
AAC, WMA, MPEG, HEAAC
|
|
Dimensions
|
|
Set dimensions (W x H x D)
|
1929.0 x 1100.0 x 69.5mm(D@wall mount) / 91.8mm(D@handle) mm
|
|
Set dimensions in inch (W x H x D)
|
75.94 x 43.31 x 2.74(@ wall mount)/ 3.61(@ handle) inch
|
|
Bezel width
|
15.5 mm (Even bezel)
|
|
Wall Mount
|
600mm x 400mm , M8
|
|
Product weight
|
49.50 kg
|
|
Product weight (lb)
|
109.13 lb
|
|
