50 Series WiFi Module with Bluetooth
Advanced 802.11a/b/g/n, 2x2 MIMO, Advanced Power Save, Enhanced BT/WiFi Coexistence, Fast Roam, Bluetooth 4.0: Enables Classic Bluetooth and Low Energy mode.
Description
Laird Connectivity's 50 Series Wi-Fi® + Bluetooth® modules achieve the best possible connectivity in any RF environment, powered by the Qualcomm Atheros QCA6004 and the Cambridge Silicon Radio CSR8811. With industry-leading software, Linux and Android support, and a wide range of form factors, Laird Connectivity’s 50 Series is a flexible option for your enterprise wireless needs. The security and robustness inherited from our expertise in our 40 and 45 Series modules means the most reliable wireless in crucial, even life-critical applications, such as medical and industrial.
Download
More Information
| Brand | Ezurio (Laird Technologies) |
|---|---|
| Specifications |
Android
Yes
BT Chipset
CSR8811
BT Dual Mode
Yes
BT Interfaces
UART
Line
Enterprise
Linux
Yes
Spatial Streams
2 (2x2 MIMO)
Supplicant
EAP
Temp Spec
-30C +85C
Wi-Fi Chipset
QCA AR6004
Wi-Fi Interfaces
1-bit or 4-bit Secure Digital I/O
|
