Shop 32BDL4031D 32" Full HD at Tekdis LLC

End of Life

SKU: 32BDL4031D-1

Signage Size: 32"

D-Line Display 32" Edge-lit LED, Full HD, 400cd/m2

Description

32" Edge-lit LED, Full HD, 400cd/m2

32"
Edge-lit LED
Full HD
400cd/m2

More Information

Brand	Philips
Specifications	Diagonal screen size (metric) 80 cm Diagonal screen size (inch) 31.5 inch Panel resolution 1920x1080p Optimum resolution 1920 x 1080 @ 60 Hz Brightness 400 cd/m² Contrast ratio (typical) 1100:1 Dynamic contrast ratio 500,000:1 Response time (typical) 8 ms Aspect ratio 16:9 Viewing angle (horizontal) 178 degree Viewing angle (vertical) 178 degree Pixel pitch 0.36375 x 0.36375 mm Display colors 16.7 Million Panel technology IPS Picture enhancement 3/2 - 2/2 motion pull down 3D Combfilter 3D MA deinterlacing Motion compens. deinterlacing Progressive scan Placement Landscape (24/7) Portrait (24/7) Supported Display Resolution Computer formats 1920 x 1200, 60Hz 1920 x 1080, 60Hz 1600 x 1200, 60Hz 1440 x 900, 60Hz 1366 x 768, 60Hz 1360 x 768, 60Hz 1280 x 800, 60Hz 1280 x 768, 60Hz 1024 x 768, 60Hz 800 x 600, 56, 60, 72, 75Hz 640 x 480, 60, 67, 72, 75Hz Video formats 1080i, 50, 60Hz 1080p, 50, 60Hz 720p, 50, 60Hz 576i, 50Hz 576p, 50Hz 480i, 60Hz 480p, 60Hz Connectivity Video input Display Port1.2x1 DVI-I x 1 HDMI (x2) Audio input 3.5 mm jack Audio output 3.5mm jack External control RJ45 RS232C (in/out) 2.5 mm jack IR (in/out) 3.5 mm jack Video output DisplayPort1.2x1 DVI-I x1 Convenience Screen saving functions Pixel Shift Tiled Matrix Up to 15 x 15 Keyboard control Lockable Hidden Network controllable RS232 RJ45 Signal Loop Through IR Loopthrough DVI Picture in picture PIP Dimensions Bezel width 10.8 mm (T/L/R), 15.7 mm (B) Set Width 724.8 mm Set Height 424.3 mm Set Depth 64.1 mm Set Width (inch) 28.54 inch Set Height (inch) 16.7 inch Set Depth (inch) 2.52 inch VESA Mount 200 x 200 mm M6 Product weight 6.15 kg Product weight (lb) 13.55 lb Operating conditions Temperature range (operation) 5 ~ 40 °C Temperature range (storage) -10 ~ 50 °C MTBF 50,000 hour(s) Altitude 0 ~ 3000 m Humidity range (operation)[RH] 10 ~ 80% (without condensation) Humidity range (storage) [RH] 0 ~ 90% (without condensation) Relative humidity 20 ~ 80 % Power Consumption (On mode) 110W( max) Mains power AC (100 ~ 240 V) , 2.5A Standby power consumption <0.5 W Consumption (Typical) 60 W Sound Built-in speakers 2 x 10W RMS Accessories Included accessories AC Power Cord RS232 cable Remote Control Batteries for remote control Quick start guide Included Accessories Edge Alignment Kit (1 )-2pcs Edge Alignment Kit (2)-1pcs M3 screw x 1 RS232 daisy-chain cable SD card cover x 1 Thumb Screw x8 Stand Universal Stand-S (BM05911)(Option) Miscellaneous Warranty 3 year warranty

Brand

Philips

Specifications

Diagonal screen size (metric)

80 cm

Diagonal screen size (inch)

31.5 inch

Panel resolution

1920x1080p

Optimum resolution

1920 x 1080 @ 60 Hz

Brightness

400 cd/m²

Contrast ratio (typical)

1100:1

Dynamic contrast ratio

500,000:1

Response time (typical)

8 ms

Aspect ratio

16:9

Viewing angle (horizontal)

178 degree

Viewing angle (vertical)

178 degree

Pixel pitch

0.36375 x 0.36375 mm

Display colors

16.7 Million

Panel technology

IPS

Picture enhancement
- 3/2 - 2/2 motion pull down
- 3D Combfilter
- 3D MA deinterlacing
- Motion compens. deinterlacing
- Progressive scan
Placement
- Landscape (24/7)
- Portrait (24/7)
Supported Display Resolution
Computer formats
- 1920 x 1200, 60Hz
- 1920 x 1080, 60Hz
- 1600 x 1200, 60Hz
- 1440 x 900, 60Hz
- 1366 x 768, 60Hz
- 1360 x 768, 60Hz
- 1280 x 800, 60Hz
- 1280 x 768, 60Hz
- 1024 x 768, 60Hz
- 800 x 600, 56, 60, 72, 75Hz
- 640 x 480, 60, 67, 72, 75Hz
Video formats
- 1080i, 50, 60Hz
- 1080p, 50, 60Hz
- 720p, 50, 60Hz
- 576i, 50Hz
- 576p, 50Hz
- 480i, 60Hz
- 480p, 60Hz
Connectivity
Video input
- Display Port1.2x1
- DVI-I x 1
- HDMI (x2)
Audio input

3.5 mm jack

Audio output

3.5mm jack

External control
- RJ45
- RS232C (in/out) 2.5 mm jack
- IR (in/out) 3.5 mm jack
Video output
- DisplayPort1.2x1
- DVI-I x1
Convenience
Screen saving functions

Pixel Shift

Tiled Matrix

Up to 15 x 15

Keyboard control
- Lockable
- Hidden
Network controllable
- RS232
- RJ45
Signal Loop Through
- IR Loopthrough
- DVI
Picture in picture

PIP
Dimensions

Bezel width

10.8 mm (T/L/R), 15.7 mm (B)

Set Width

724.8 mm

Set Height

424.3 mm

Set Depth

64.1 mm

Set Width (inch)

28.54 inch

Set Height (inch)

16.7 inch

Set Depth (inch)

2.52 inch

VESA Mount

200 x 200 mm M6

Product weight

6.15 kg

Product weight (lb)

13.55 lb
Operating conditions

Temperature range (operation)

5 ~ 40 °C

Temperature range (storage)

-10 ~ 50 °C

MTBF

50,000 hour(s)

Altitude

0 ~ 3000 m

Humidity range (operation)[RH]

10 ~ 80% (without condensation)

Humidity range (storage) [RH]

0 ~ 90% (without condensation)

Relative humidity

20 ~ 80 %
Power

Consumption (On mode)

110W( max)

Mains power

AC (100 ~ 240 V) , 2.5A

Standby power consumption

<0.5 W

Consumption (Typical)

60 W
Sound

Built-in speakers

2 x 10W RMS
Accessories
Included accessories
- AC Power Cord
- RS232 cable
- Remote Control
- Batteries for remote control
- Quick start guide
Included Accessories
- Edge Alignment Kit (1 )-2pcs
- Edge Alignment Kit (2)-1pcs
- M3 screw x 1
- RS232 daisy-chain cable
- SD card cover x 1
- Thumb Screw x8
Stand

Universal Stand-S (BM05911)(Option)
Miscellaneous

Warranty

3 year warranty
